    Stainless Steel Screen Custom FOD Filter For Aircraft Turbine Jet Engines

    Ask Lasest Price
    Brand Name : Share Filters
    Model Number : Custom FOD Screen Guard Filter
    Certification : SGS
    Price : USD4.00-USD9.00/pc
    Payment Terms : T/T, L/C, Western Union, PayPle
    Supply Ability : 10000pcs/day
    Delivery Time : 7-20 days
    • Product Details
    • Company Profile

    Stainless Steel Screen Custom FOD Filter For Aircraft Turbine Jet Engines


    Custom Fod Filter With Stainless Steel Screen For Aircraft Turbine Jet Engines

    A FOD (Foreign Object Damage) filter is exclusively designed and manufactured for Jets Munt Turbines, it's an essential component for protecting jet engines, including those manufactured by Jets Munt. FOD filters are designed to prevent foreign objects, such as debris, dust, or small particles, from entering the engine during operation. These filters help maintain the performance, reliability, and longevity of the turbine.


    Share Filters' FOD filter meets relevant industry standards and regulations for aviation safety. It consists of a stainless steel mesh held in a polymer plastic frame, allowing for a more robust part/product giving more reliability and longevity in its use. This filter is durable and replaceable. This type of filter tends to be the larger practical. It is very easy to installation.


    Upside diam: custom size

    Down side diam: custom size

    Height: custom size

    FOD screen material: stainless steel or galvanized

    FOD screen micron: by specify

    Application: protects jet engine absorbing larger objects

    FOD guard filter

    FOD guard filter

    Share Filters Plastic Molded Filters Options

    Support frame materialPA6, PA66, PET, PP, ABS, and other thermoplastics
    Filter mediaMetallic mesh, Nylon mesh, polyester mesh, PP mesh,
    Micron rating3μm - 3000μm
    Mesh parts fabricationLaser cutting, punching
    ProcessingInsert injection molded filter, over moulding
    SpecificationCustom
    ColorCustom

    How to Select the Right Filter Mesh?

    You can follow these points.

    • Opening size or the size of the particle you need to filter
    • Mesh material (consider the working condition)
    • Mesh thread diameter, mesh thickness
    • Opening area

    Stainless Filter Mesh Specification

    Mesh count (per inch)Thread diameter (microns)ApertureOpen Area (%)Weight (IB) /100 square foot
    InchmmInchmm
    1x10.0802.030.92023.3784.641.1
    2x20.0631.600.43711.1076.451.2
    3x30.0541.370.2797.0970.156.7
    4x40.0631.600.1874.7556.0104.8
    4x40.0471.190.2035.1665.957.6
    5x50.0411.040.1594.0463.254.9
    6x60.0350.890.1323.3562.748.1
    8x80.0280.710.0972.4660.241.1
    10x100.0250.640.0751.9156.341.2
    10x100.0200.510.0802.0364.026.1
    12x120.0230.5840.0601.5251.842.2
    12x120.0200.5080.0631.6057.231.6
    14x140.0230.5840.0481.2245.249.8
    14x140.0200.5080.0511.3051.037.2
    16x160.0180.5080.04451.1350.734.5
    18x180.0170.4320.03860.9848.334.8
    20x200.0200.5080.03000.7636.055.2
    20x200.0160.4060.03400.8646.234.4
    24x240.0140.3560.02770.7044.231.8
    30x300.0130.3300.02030.5237.134.8
    30x300.0120.3050.02130.5440.829.4
    30x300.0090.2290.02430.6253.116.1
    35x350.0110.2790.01760.4537.929.0
    40x400.0100.2540.01500.3836.027.6
    50x500.0090.2290.01100.2830.328.4
    50x500.0080.2030.01200.3136.022.1
    60x600.00750.1910.00920.2330.523.7

    Share Filters, an OEM Mesh Insert Molded Filters Manufacture From China

    As an filter meshes and filter components manufacture , Share Filters always find the best solution is to work with our OEM customers to collaborate on their mesh filtration product development projects before the final design prints are completed. Our experienced engineers are able to not only to meet your functional requirements, but also to recommend design alterations to improve performance and manufacturability. We will concentrate on the following:

    Consider Area

    Factors


    Outcoming


    Filtration
    Media

    filter meshSelect right material, weave, pore, thread diam, heat treatment, coatingsMedia selected meets the required performance


    Component Design

    injection suport cageConsider supporting media, housing, end capsTher filtration components can perform well in working condition


    Manufacturing Process

    injection moldingDesign lends itself to easy manufacture and economic cost?Produced at low cost of manufacture and hign efficiency


    Quality Control

    double measure during the productionDetermine parameters and frequency of measurementHigh quality, precision filter components

    Manufacturing - High Quality Materials, Precise Workmanship
    In our factory we process woven filter mesh for screens and filters in all sizes and designs. Our business activities span from cutting or punching to sewing, gluing and welding to insert-molding of the different fabrics.


    We manufacture according to customer drawing as well as to freehand sketch or model, considering the underlying standard tolerances and customized manufacturing standards. Experience and knowledge of our employees guarantee high-quality implementation.


    Custom Plastic Molded Filters

    fuel filter petrol filter spray filter

    As a primary mesh supplier serving filtration OEM filters, you can benefit from Share's experience helping our customers develop thousands of products by engaging with our filtration solutions team. Contact us now if you have filtration inquiry.
