SHARE food grade nylon mesh features anti aging, wear resistance, pressure resistance and high temperature resistance. Our mesh is deal for a wide range of applications in the food, beverage, medical, chemical, industrial, and pharmaceutical field, such as rosin bags, paint filters, automotive filters, air purifier filters, air conditioner filters, circulating and wastewater filters, cell strainers, blood transfusion filters, wound care, injector filtration, coffee filters, biopsy bags, milling meshes, test/sample sieves, filters for agricultural instruments, and filtration of powder and liquid chemicals etc.
Our laser cutting technology ensures the production of highly precise fabric discs and sheets with heat sealed edges. To meet varied filtration needs of our customers, SHARE has imported high speed custom laser cutting machines equipped with CAD software, featuring semi-automated vision systems and fully automated AI programming, to make sure the precision and consistency of the final filter products.
Contact SHARE now for more information.
| Item Name | Food Grade Square Nylon Micron Woven Filter Mesh |
| Manufacturer | Taizhou Share Filters Co., Ltd. |
| Material | Nylon |
| Dimensions | 6''x6", 12''x12" or customized size |
| Pore Size | 15um and 25um |
| Shape | Square |
| Process Technology | Laser cutting |
| Features | Moderately hydrophilic Good resistance against alkalis, organics and corrosives Resistant against pH 3 to 14 |
| Certificate | Reach Svhc, SGS RoHS, US California Proposition 65 |
| Application | Sifting kief pre-pressed concentrates and isolates |
| Precision Nylon Filter Mesh Technical Data Sheet |
| Fabric Number | Mesh Count | Thread Diameter | Mesh Opening | Open Area | Mesh Thickness | Weight |
| No. | n/cm | n/inch | μm | μm | % | μm | g/m2 |
| PA 3233/58.3 | 2.3 | 6 | 1000 | 3233 | 58.3 | 1900 | 412 |
| PA 2300/51.3 | 3.1 | 8 | 900 | 2300 | 51.3 | 1700 | 450 |
| PA 1950/61 | 4 | 10 | 550 | 1950 | 61 | 950 | 262 |
| PA 1500/58 | 5 | 12 | 500 | 1500 | 58 | 850 | 271 |
| PA 1267/56 | 6 | 16 | 400 | 1267 | 56 | 780 | 208 |
| PA 1079/57 | 7 | 18 | 350 | 1079 | 57 | 675 | 186 |
| PA 900/52 | 8 | 20 | 350 | 900 | 52 | 685 | 212 |
| PA 860/58 | 9 | 24 | 250 | 860 | 58 | 455 | 145 |
| PA 700/49 | 10 | 25 | 300 | 700 | 49 | 576 | 195 |
| PA 583/49 | 12 | 30 | 250 | 583 | 49 | 470 | 162 |
| PA 533/41 | 12 | 30 | 300 | 533 | 41 | 585 | 234 |
| PA 414/34 | 14 | 35 | 300 | 414 | 34 | 595 | 273 |
| PA 425/46 | 16 | 40 | 200 | 425 | 46 | 370 | 139 |
| PA 375/36 | 16 | 40 | 250 | 375 | 36 | 485 | 217 |
| PA 350/49 | 20 | 50 | 150 | 350 | 49 | 375 | 98 |
| PA 300/36 | 20 | 50 | 200 | 300 | 36 | 385 | 173 |
| PA 267/41 | 24 | 60 | 150 | 267 | 41 | 285 | 117 |
| PA 237/44 | 28 | 70 | 120 | 237 | 44 | 215 | 87 |
| PA 213/41 | 30 | 76 | 120 | 213 | 41 | 225 | 94 |
| PA 213/46 | 32 | 80 | 100 | 213 | 46 | 165 | 69 |
| PA 178/41 | 36 | 90 | 100 | 178 | 41 | 178 | 78 |
| PA 150/36 | 40 | 100 | 100 | 150 | 36 | 190 | 87 |
| PA 152/42 | 43 | 110 | 80 | 152 | 42 | 135 | 60 |
| PA 130/38 | 48 | 120 | 80 | 130 | 38 | 145 | 62 |
| PA 120/44 | 56 | 140 | 60 | 120 | 44 | 85 | 44 |
| PA 110/41 | 59 | 150 | 60 | 110 | 41 | 98 | 46 |
| PA 100/38 | 64 | 160 | 60 | 100 | 38 | 105 | 50 |
| PA 90/41 | 72 | 180 | 50 | 90 | 41 | 82 | 39 |
| PA 75/36 | 80 | 200 | 50 | 75 | 36 | 90 | 43 |
| PA 60/34 | 100 | 250 | 42 | 60 | 34 | 65 | 35 |
| PA 42/24 | 120 | 305 | 42 | 42 | 24 | 75 | 42 |
| PA 44/29 | 120 | 305 | 38 | 44 | 29 | 72 | 35 |
| PA 42/25 | 120 | 305 | 38 | 42 | 25 | 67 | 35 |
| PA 45/33 | 120 | 305 | 35 | 45 | 33 | 60 | 28 |
| PA 55/40 | 120 | 305 | 30 | 55 | 40 | 52 | 20 |
| PA 40/25 | 130 | 330 | 38 | 40 | 25 | 74 | 36 |
| PA 42/29 | 130 | 330 | 35 | 42 | 29 | 62 | 30 |
| PA 47/37 | 130 | 330 | 30 | 47 | 37 | 55 | 22 |
| PA 32/21 | 140 | 355 | 38 | 32 | 21 | 68 | 36 |
| PA 37/26 | 140 | 355 | 35 | 37 | 26 | 65 | 33 |
| PA 38/33 | 140 | 355 | 30 | 38 | 33 | 53 | 25 |
| PA 31/18 | 150 | 380 | 38 | 31 | 18 | 68 | 40 |
| PA 35/29 | 150 | 380 | 30 | 35 | 29 | 57 | 26 |
| PA 34/26 | 150 | 380 | 30 | 34 | 26 | 50 | 26 |
| PA 30/25 | 165 | 420 | 30 | 30 | 25 | 59 | 28 |
| PA 30/19 | 145 | 368 | 38 | 30 | 19 | 64 | 40 |
| PA 25/21 | 180 | 460 | 30 | 25 | 21 | 60 | 31 |
| PA 25/15 | 165 | 420 | 38 | 25 | 15 | 75 | 42 |
| PA 20/16 | 200 | 508 | 30 | 20 | 16 | 65 | 34 |
| PA 10/4.3 | 208 | 530 | 38 | 10 | 4.3 | 77 | 53 |
| PA 8/3 | 220 | 560 | 38 | 8 | 3 | 78 | 56 |
| PA 6/1.7 | 228 | 580 | 38 | 6 | 1.7 | 80 | 59 |
| PA 3/1 | 236 | 600 | 38 | 3 | 1 | 85 | 61 |
| PA 1/2 | 256 | 650 | 34*38 | 1 | 2 | 80 | 62 |
| PA 2/1 | 275 | 700 | 34*38 | 2 | 1 | 80 | 66 |
| PA10GG | 4 | 10 | 550 | 2000 | 61 | 950 | 238 |
| PA12GG | 4.5 | 11 | 400 | 1822 | 67 | 760 | 153 |
| PA14GG | 5 | 13 | 400 | 1600 | 64 | 770 | 170 |
| PA15GG | 5.5 | 14 | 400 | 1418 | 61 | 780 | 187 |
| PA16GG | 6 | 15 | 350 | 1317 | 62 | 665 | 156 |
| PA18GG | 6.5 | 17 | 350 | 1180 | 59 | 670 | 170 |
| PA19GG | 7 | 18 | 350 | 1079 | 57 | 675 | 182 |
| PA20GG | 7.5 | 19 | 300 | 1023 | 60 | 560 | 144 |
| PA22GG | 8 | 20 | 300 | 950 | 58 | 560 | 153 |
| PA24GG | 8.5 | 22 | 300 | 876 | 56 | 565 | 163 |
| PA26GG | 9 | 23 | 300 | 811 | 54 | 570 | 172 |
| PA27GG | 10 | 25 | 250 | 750 | 56 | 475 | 133 |
| PA28GG | 10.5 | 27 | 250 | 702 | 54 | 475 | 140 |
| PA30GG | 11 | 28 | 250 | 659 | 53 | 480 | 146 |
| PA31GG | 11.5 | 29 | 250 | 619 | 51 | 485 | 153 |
| PA34GG | 12 | 30 | 250 | 583 | 49 | 490 | 159 |
| PA36GG | 12.5 | 32 | 250 | 550 | 47 | 490 | 166 |
| PA38GG | 14 | 36 | 200 | 514 | 52 | 360 | 119 |
| PA40GG | 14.5 | 37 | 200 | 489 | 50 | 365 | 123 |
| PA42GG | 15 | 38 | 200 | 466 | 49 | 365 | 128 |
| PA44GG | 16 | 41 | 200 | 425 | 46 | 370 | 136 |
| PA46GG | 17 | 43 | 200 | 388 | 44 | 375 | 145 |
| PA50GG | 18 | 46 | 200 | 355 | 41 | 380 | 153 |
| PA52GG | 20.5 | 52 | 150 | 338 | 48 | 270 | 98 |
| PA54GG | 21.5 | 55 | 150 | 315 | 46 | 275 | 103 |
| PA58GG | 22 | 56 | 150 | 304 | 45 | 275 | 105 |
| PA60GG | 23 | 58 | 150 | 285 | 43 | 280 | 110 |
| PA62GG | 23.5 | 60 | 150 | 275 | 42 | 285 | 112 |
| PA64GG | 24 | 61 | 150 | 267 | 41 | 285 | 115 |
| PA66GG | 28.5 | 72 | 100 | 251 | 51 | 163 | 61 |
| PA68GG | 29 | 74 | 100 | 245 | 50 | 165 | 63 |
| PA70GG | 29.5 | 75 | 100 | 239 | 48 | 166 | 64 |
| PA72GG | 30.5 | 77 | 100 | 227 | 47 | 168 | 66 |
| PA74GG | 32 | 81 | 100 | 213 | 46 | 170 | 69 |
| PA-6XXX | 30 | 76 | 120 | 213 | 40 | 225 | 94 |
| PA-7XXX | 31 | 79 | 120 | 200 | 40 | 228 | 98 |
| PA-8XXX | 35.5 | 90 | 100 | 182 | 42 | 178 | 78 |
| PA-8.5XXX | 38 | 97 | 100 | 163 | 38 | 190 | 84 |
| PA-9XXX | 41 | 104 | 90 | 154 | 40 | 170 | 60 |
| PA-9.5XXX | 43 | 109 | 90 | 143 | 38 | 175 | 63 |
| PA-10XXX | 47 | 117 | 80 | 135 | 39 | 145 | 61 |
| PA-10.5XXX | 49 | 124 | 80 | 125 | 37 | 146 | 64 |
| PA-11XXX | 50 | 130 | 80 | 115 | 36 | 147 | 65 |
| PA-12XXX | 55 | 140 | 70 | 112 | 38 | 130 | 48 |
| PA-12.5XXX | 57 | 145 | 70 | 105 | 36 | 132 | 50 |
| PA-13XXX | 59 | 150 | 70 | 99 | 35 | 135 | 52 |
| PA-14XXX | 60 | 152 | 70 | 97 | 34 | 136 | 53 |
| PA-15XXX | 66 | 168 | 60 | 92 | 36 | 108 | 53 |
| PA-16XXX | 69 | 175 | 60 | 85 | 35 | 110 | 55 |
| PA-17XXX | 71 | 180 | 60 | 81 | 33 | 112 | 57 |
The data are compiled to the best of our knowledge.
Subject to change without notice.
Complete product range is available on request.
SHARE has the ability to engineer woven mesh fabrics into finished or partly finished products, such as various types of cut-to-size filter stamped discs, pieces, shapes, ribbons, tubes, bags, injection molded filter products etc . With its industrial lines and long-standing experience, we provide fabrics cut to size, lot-to-lot consistency and high quality custom fabricated components, in almost any requested shapes.
|
SHARE Fabricated Product
| SHARE Fabrication Capabilities |
| COLD | HEAT | ULTRASONICS | LASER |
| Continuous & tubular ribbons | Ribbon | Ribbon | Ribbon | |
| | Double seam tubular ribbon | Double seam tubular
ribbon | |
| | Multiple layer ribbon | Multiple Layer ribbon | |
| | | Multiple layer tubular
ribbon | |
| | | Single seam tubular
ribbon | |
| Tubes & Rectangles | Filter segment, two sides heat cut,
two sides cold cut | Rectangle, four sides
ultrasonically cut | |
| | Rectangle, two sides heat cut and two sides ultrasonically cut | |
| Tube, two open ends | Tube, two open ends,
hot wire cut | | |
| | | Tube, one end sealed | Tube, two open ends, laser cut |
| | | Tube special execution
(single/double layer) | |
| | | Biopsy bag with or
without flaps | |
| Shapes | Cold punched part
(single layer) | | Punched part
(single or multiple layer) | Single layer shapes,
laser cut |
| Pleated Element | | | Pleated pack
(ultrasonically cross cut) | |
| | | Pleated cartridges
(ultrasonically sealed) | |
Cone Shaped
(Truncated) | | | Single seam | |
| | Double seam
(single/double layer) | |
Why SHARE?
Wide Ranges of Materials and Micron Rating Options
Rolls, Pieces, Shapes, Ribbons, Tubes, Molded Products
Precision Unifom Mesh Opening
Smooth Surface
Custom Cutting Service, Tight Tolerances
Unlimited Shapes, Clean Sealed Edges
Free Samples
2 Days or Less Lead Time
SHARE application speciallists with decades of years experiences will help you select the best filter solution for your application. Contact us now to discuss how SHARE FILTERS can revolutionize your filtration needs.
Company Profile
Established in 1983, Taizhou Share Filters Co., Ltd. offers a comprehensive range of woven monofilament filter mesh fabrics(nylon, polyester, polypropylene etc.) with micron ratings ranging from 3um to 4mm. We specialize in engineering woven fabrics into finished or partly finished products.
Our products ranges:
- Monofilament Mesh Rolls
- Discs, Tubes, Ribbons, Bags
- Plastic Molded Filters
Whether you want to improve the quality or reduce the cost of your existing filter component, plan a new filtration application, or need assistance with specifications and design validation, SHARE application specialists with decades of experience will help you create the best filter solution for your application.
Contact SHARE today for additional information and how we can help you with your specific filtration requirements.
Packaging & Shipping
For mesh rolls:
1. Rolled on the paper core, 30-70m/roll, packed into PE bags, the product label is attached on the edge of each roll
2. 2-8 rolls per standard export carton
3. Put into PP woven bag to prevent damage during transportation
4. Package belt strengthen
For fabricated & molded filters:
1. Packed into sealed PE bags, 10pcs to 500pcs/bag according to the actual size, double bagged and the product label is attached in the inner bag
2. Put into bigger PE bag and then standard export carton
3. Wrapped the outer carton with PE stretch film to prevent damage during transportation
4. Package belt strengthen if pallets are available
The label contains the following standard information:
item name, manufacturer, material, dimensions, manufacturing date, order number, batch number etc.
| | Port to Port | Door to Door |
| Express(DHL,UPS,FEDEX, EMS) | | 1 - 5 days |
| Air Freight | 1 - 5 days | 4 - 10 days |
| Sea Freight(FCL) | 15 - 30 days | 20 - 35 days |
| Sea Freight(LCL) | 15 - 30 days | 22 - 37 days |
FAQ
1. Where is your factory located? How can I visit there?
We are in Taizhou city, Zhejiang province China. By train, we are one hour away from Hangzhou and two hours away from Shanghai.
2. Can I get free samples and how long can you deliver them?
We are pleased to provide you with free samples for your evaluation, which will be sent to you within 2 days. Please feel free to reach out to us for samples.
3. How long does a quotation take?
In most cases, we respond within 2 days. If something in RFQ need be confirmed, we will promptly notify you soon.
4. How quickly can I get my order finished?
The production lead time is dependent on the quantity. Typically, it takes 5 to 15 working days for us to complete mass production once you have placed the order.
5. What about your quality control?
By visual inspection, optical or pressure sensitive equipment and automated 3D image-inspection equipment, our production operators conduct self-inspections at every stage of the process. Additionally, we have spot inspections and final inspections carried out by our Quality Control (QC) team.
6. What's your largest advantage?
One of our core competencies is our excellent converting capabilities from yarn over weaving to converted items with professional technical team and quality guarantee and management for more than 30 years.
7. What kind of payment terms do you accept?
T/T and LC and more.
