    Nylon Monofilament Woven Filter Mesh Fabrics Compliant With SGS RoHS, REACH Svhc And US California Prop 65 Regulations

    Ask Lasest Price
    Brand Name : SHARE FILTERS
    Model Number : SG-NF-41
    Certification : Reach Svhc, SGS RoHS, US California Proposition 65
    Price : $1 for 1000 M2, $0.9 for 5,000 M2, $0.8 for 20, 000 M2
    Payment Terms : L/C, T/T, Paypal
    Supply Ability : 10, 0000 M2 / Day
    Delivery Time : 5 Working Days
    • Product Details
    • Company Profile

    Nylon Monofilament Woven Filter Mesh Fabrics Compliant With SGS RoHS, REACH Svhc And US California Prop 65 Regulations



    SHARE nylon filter mesh has the advantages of good abrasion, excellent fuel and oil resistance, good fatigue resistance, good impact strength even at low temperature, high strength and stiffness at high temperature, low dimensional stability, attacked by strong mineral acids and absorbs polar solvents, so it is an ideal material of filtration, screening and sifting for automotive, biomedical, chemical processing, food industry and water treatment applications.


    SHARE plain weave nylon woven mesh is woven by 100% monofilament yarn. In plain weave constructions the straight-through pores of monofilament fabrics offer minimal flow restriction and surface loading of particles.


    Precision Nylon Monofilament Filter Mesh

    - Excellent diameter control for precise openings
    - High flow rates and low pressure drops
    - Filtration by surface particle capture
    - Excellent surface particle release easy to clean
    - High degree of stiffness



    SHARE provides a broad range of nylon monofilament woven mesh, characterized by precise mesh openings, open area and mesh thickness.

    Mesh Opening: The distance between adjacent threads
    Open Area: The ratio (%) of the open area to the thread area within a woven mesh
    Mesh Thickness: The average thickness of the woven mesh


    Precision Nylon Filter Mesh Technical Data Sheet
    Fabric NumberMesh CountThread DiameterMesh OpeningOpen AreaMesh ThicknessWeight
    No.n/cmn/inchμmμm%μmg/m2
    PA 3233/58.32.361000323358.31900412
    PA 2300/51.33.18900230051.31700450
    PA 1950/61410550195061950262
    PA 1500/58512500150058850271
    PA 1267/56616400126756780208
    PA 1079/57718350107957675186
    PA 900/5282035090052685212
    PA 860/5892425086058455145
    PA 700/49102530070049576195
    PA 583/49123025058349470162
    PA 533/41123030053341585234
    PA 414/34143530041434595273
    PA 425/46164020042546370139
    PA 375/36164025037536485217
    PA 350/4920501503504937598
    PA 300/36205020030036385173
    PA 267/41246015026741285117
    PA 237/4428701202374421587
    PA 213/4130761202134122594
    PA 213/4632801002134616569
    PA 178/4136901001784117878
    PA 150/36401001001503619087
    PA 152/4243110801524213560
    PA 130/3848120801303814562
    PA 120/445614060120448544
    PA 110/415915060110419846
    PA 100/3864160601003810550
    PA 90/41721805090418239
    PA 75/36802005075369043
    PA 60/341002504260346535
    PA 42/241203054242247542
    PA 44/291203053844297235
    PA 42/251203053842256735
    PA 45/331203053545336028
    PA 55/401203053055405220
    PA 40/251303303840257436
    PA 42/291303303542296230
    PA 47/371303303047375522
    PA 32/211403553832216836
    PA 37/261403553537266533
    PA 38/331403553038335325
    PA 31/181503803831186840
    PA 35/291503803035295726
    PA 34/261503803034265026
    PA 30/251654203030255928
    PA 30/191453683830196440
    PA 25/211804603025216031
    PA 25/151654203825157542
    PA 20/162005083020166534
    PA 10/4.320853038104.37753
    PA 8/322056038837856
    PA 6/1.72285803861.78059
    PA 3/123660038318561
    PA 1/225665034*38128062
    PA 2/127570034*38218066
    PA10GG410550200061950238
    PA12GG4.511400182267760153
    PA14GG513400160064770170
    PA15GG5.514400141861780187
    PA16GG615350131762665156
    PA18GG6.517350118059670170
    PA19GG718350107957675182
    PA20GG7.519300102360560144
    PA22GG82030095058560153
    PA24GG8.52230087656565163
    PA26GG92330081154570172
    PA27GG102525075056475133
    PA28GG10.52725070254475140
    PA30GG112825065953480146
    PA31GG11.52925061951485153
    PA34GG123025058349490159
    PA36GG12.53225055047490166
    PA38GG143620051452360119
    PA40GG14.53720048950365123
    PA42GG153820046649365128
    PA44GG164120042546370136
    PA46GG174320038844375145
    PA50GG184620035541380153
    PA52GG20.5521503384827098
    PA54GG21.55515031546275103
    PA58GG225615030445275105
    PA60GG235815028543280110
    PA62GG23.56015027542285112
    PA64GG246115026741285115
    PA66GG28.5721002515116361
    PA68GG29741002455016563
    PA70GG29.5751002394816664
    PA72GG30.5771002274716866
    PA74GG32811002134617069
    PA-6XXX30761202134022594
    PA-7XXX31791202004022898
    PA-8XXX35.5901001824217878
    PA-8.5XXX38971001633819084
    PA-9XXX41104901544017060
    PA-9.5XXX43109901433817563
    PA-10XXX47117801353914561
    PA-10.5XXX49124801253714664
    PA-11XXX50130801153614765
    PA-12XXX55140701123813048
    PA-12.5XXX57145701053613250
    PA-13XXX5915070993513552
    PA-14XXX6015270973413653
    PA-15XXX6616860923610853
    PA-16XXX6917560853511055
    PA-17XXX7118060813311257

    The data are compiled to the best of our knowledge.

    Subject to change without notice.
    Complete product range is available on request.

    What SHARE can do for you?

    SHARE has the ability to engineer woven mesh fabrics into finished or partly finished products. With its industrial lines and long-standing experience, we provide fabrics cut to size, lot-to-lot consistency and high quality custom fabricated components, in almost any requested shapes.

    SHARE application speciallists with decades of years experiences will help you select the best filtration solution for your application.



    Your Benefits

    • Wide range of filter materials(mainly in nylon, polyester, polypropylene, stainless steel) and micron sizes available
    • Supplied in the form of rolls, pieces, shapes, ribbons, tubes, plastic molded products
    • Precision unifom mesh opening and clean smooth surface
    • Custom cutting and molding service, tight tolerances
    • Unlimited shapes, non-fraying sealed edges
    • Free samples
    • 2 days or less lead time

    Packging & Shipping


    ​1. For rolls:


    1. Rolled on the paper core, 30-70m/roll, packed into PE bags, the product label is attached on the edge of each roll
    2. 2-8 rolls per standard export carton
    3. Put into PP woven bag to prevent damage during transportation
    4. Package belt strengthen

    2. For fabricated filters:


    1. Packed into sealed PE bags, 10pcs to 500pcs/bag according to the actual size, double bagged and the product label is attached in the inner bag
    2. Put into b
    igger PE bag and then standard export carton
    3. W
    rapped the outer carton with PE stretch film to prevent damage during transportation
    4.
    Package belt strengthen if pallets are available

    The label contains the following standard information:
    item name, manufacturer, material, dimensions, manufacturing date, order number, batch number etc.


    pingFAQ


    1. Who are we?

    Established in 1983, SHARE offers a comprehensive range of industrial filter fabrics from 3 micron to 2500 microns openings: nylon filter mesh, polyester filter mesh, polypropylene filter mesh, polyethylene filter mesh, metallic filter mesh, PPS, PTFE, PEEK, etc., and we convert filter fabrics to fabricated filters and injection molded filters.

    Our products and solutions for filtration, separation and sifting are applied to a wide range of industries, such as home appliances, automotive, irrigation, medical and healthcare, food and beverage, milling, electronics, aerospace etc.

    2. Where is your factory located? How can I visit there?
    We are in Taizhou city, Zhejiang province China. By train, we are one hour away from Hangzhou and two hours away from Shanghai.

    3. Can I get free samples and how long can you deliver them?
    We are pleased to provide you with free samples for your evaluation, which will be sent to you within 2 days. Please feel free to reach out to us for samples.


    4. How long does a quotation take?
    In most cases, we respond within 2 days. If something in RFQ need be confirmed, we will promptly notify you soon.

    5. How quickly can I get my order finished?
    The production lead time is dependent on the quantity. Typically, it takes 5 to 15 working days for us to complete mass production once you have placed the order.

    6. What about your quality control?
    By visual inspection, optical or pressure sensitive equipment and automated 3D image-inspection equipment, our production operators conduct self-inspections at every stage of the process. Additionally, we have spot inspections and final inspections carried out by our Quality Control (QC) team.


    7. What's your largest advantage?
    One of our core competencies is our excellent converting capabilities from yarn over weaving to converted items with professional technical team and quality guarantee and management for more than 30 years.

    8. What kind of payment terms do you accept?
    T/T and LC and more.
