    Low Elongation Polyester Silk Screen Printing Mesh Bolting Cloth

    Ask Lasest Price
    Brand Name : SHARE
    Model Number : 8/20-300W,165/420-27W
    Certification : SGS
    Price : USD0.2-USD3.5/m
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 10000m/month
    Delivery Time : 5-15 days
    • Product Details
    • Company Profile

    Low Elongation Polyester Silk Screen Printing Mesh Bolting Cloth

    Our polyester monofilament woven screen meshes have excellent tear resistance which permits high fabric tensions to be achieved with virtually any commercially available stretching system. And very good dimensional stability guarantees highly reproducible tension.


    Woven by monofilament Yarn/threads, polyester screen-printing mesh is seen wide applications in different industrial printing, such as glass printing, graphic printing, ceramic printing, paper printing, circuited board printing, plastics and packaging printing...

    Characteristics:

    1. Screen printing makes it possible to print on wide range of substrates.
    2. Screen printing makes it possible to print on the substrates with various shapes and sizes.
    3. Many kinds of ink are available.
    4. Thick coating is possible. (General stencil: 10-30 microns, Special stencil: more than 100 microns)
    5. Thick coating makes colors more vivid, finish more opaque and light-fastness better.
    6. As printing pressure is small, it is possible to print on fragile matters.
    7. As the stencil is soft, it is possible to print on hard materials such as glass and metal as well as soft materials such as
    paper and fabrics.
    8. The stencil is cheap, which is the advantage in case of production of small quantity.
    Low Elongation Polyester Silk Screen Printing Mesh Bolting Cloth
    Product Datesheet:

    Mesh count

    (per cm/inch)

    Type of weave

    (tw or pw)

    Thread diameter (microns)Mesh opening (microns)Overall fabric thickness (microns)% Open areaTheoretical
    ink deposit (cm3/m2)
    Mesh Weight (gsm)
    40/103-80WPW8016613344.158.660
    43/110-80WPW8014913040.853.064
    45/115-80WPW8013813038.750.367
    48/123-80WPW8012213034.544.872
    48/123-55WPW551519052.847.534
    51/131-70WPW7012111438.143.558
    54/137-64WPW6411510338.739.851
    61/156-64WPW649010130.130.458
    68/175-55WPW55858733.528.448
    68/175-64WPW64789828.227.665
    71/180-55WPW55799031.528.451
    77/195-48WPW48778035.028.042
    77/195-55WPW55678726.523.355
    82/206-48WPW48687930.824.344
    90/230-40WPW40686537.624.433
    90/230-48WPW48557824.619.249
    100/255-40WPW40576432.521.137
    110/280-34WPW34545535.219.331
    110/280-40WPW40476526.617.340
    120/305-34WPW34455529.616.334
    120/305-40WPW40376420.113.044
    130/330-34WPW34405526.914.337
    140/355-34WPW34315519.410.639
    150/380-34WPW34235512.16.642
    165/420-34WPW34236213.98.646
    Production Procedure
