    Corrosion Resistance Nylon Screen Printing Mesh Galss And Tile Thread Diam 30-300μM

    Ask Lasest Price
    Brand Name : SHARE
    Model Number : 77/195-55W, 90/230-40W, 150/380-34W, 165/420-34W
    Certification : SGS
    Price : USD0.25-USD4.50/meter
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000meters/day
    Delivery Time : 7-30 days
    • Product Details
    • Company Profile

    Corrosion Resistance Nylon Screen Printing Mesh Galss And Tile Thread Diam 30-300μM

    Corrosion Resistance Nylon Screen Printing Mesh Galss And Tile


    The nylon printing Mesh has high strength, so the plane stability is good, and there is no downward depression or upward convexity during the printing process, The nylon Mesh has good tensile recovery rate and elasticity, even if it is subjected to strong impact. In the case of damage, the original shape can be restored and used; the nylon Mesh has strong corrosion resistance and is not easily damaged during the printing process, and the nylon Screen Printing Mesh is mainly used for curved surface printing


    Nylon Screen Printing Mesh is a polyamide mesh. Nylon meshes are the oldest monofilament chemical fiber meshes used for industrial screen printing. The key characteristics of nylon are mechanical resistance, excellent elasticity and very good ink flow.


    nylon screen printing mesh


    Nylon Screen Printing Mesh Features:

    • Excellent abrasion resistance of the yarn material
    • Good mechanical and chemical resistance
    • Mesh surface has excellent adhesion properties
    • HighFlexible and elastic
    • Very good ink flow properties

    nylon filter mesh



    These properties make nylon printing mesh mak it ideal for printing onto curved or rigid surfaces. Additionally, it provides reliable mechanical resistance and good emulsion adhesion, making it especially suitable for printing with an abrasive paste or substrate, and other challenging surfaces, such as:


    screen printing on creamicscreen printing mesh on glassscreen printing on labelscreen printing on plastic bottlescreen printing on tiles

    Ceramic

    GlassLabelPlastic containersTiles

    How to Decide Which Mesh Count You Should Use?

    To decide which mesh count you need to use, you should consider the details of the print:

    • What ink is being used?
    • What material (substrate) is being printed on?
    • How much detail does the image have?

    One of the most important parts of successful screen printing is understanding how mesh count relate to print quality. Screens printing come in a wide range of mesh options. Ultimately, it’s virtual to understand which mesh works with each garment, each image, and each ink.


    Nylon Screen Printing Mesh Datasheet


    Ref. No.Mesh CountThread Diam.Mesh OpeningOpening Area
    mesh/cmmesh/inchµmµm%
    JPP64641606010037
    JPP7272180509041
    JPP8080200507536
    JPP100100250406036
    JPP120120305404325
    JPP130130330403723
    JPP140140355303833.7
    JPP150150381303430.25
    JPP165165420302820.7
